General Description

 General Description:

 GFRC-ZeamentTM glass fiber reinforced concrete

 A composite consisting of Portland Cement, sand, aggregates, alkali resistant fiber, polymer, adhesives and water

Installation:

All substrates must be properly constructed to verify substrate is plumb and true

 Architects Specifications

 Part One - General
 A. Description - Internal and exterior architectural detail and millwork shall be ZeamentTM

     - as distributed by Imperial Productions and Distribution Inc.

 Part Two - Submittals
 A. Product Data: Submit manufacturer's descriptive literature, specifications, installation instructions

       and limited warranties.

 B. Warranty: Manufacturer's Limited One Year Warranty is to be submitted.

 C. Product Material Specifications: Obtain from the manufacturer for submission to the relevant

      building code authority.

Part Three - Substitutions
A. Substitutions from Imperial's specified architectural details and building components will be allowed only with the express written consent of the Owner or Architect.

 Part Four - Product Materials
 A. All interior/exterior GFRC-ZeamentTM products as distributed by Imperial Productions & Distribution Inc.

 B. Imperial distributed products are vermin resistant and resistant to mold and mildew.

 Part Five - Delivery, Storage and Installation
A. Deliver, store and install according to instructions as provided by Imperial Productions & Distribution Inc.

B.

Installation instructions as provided by Imperial Productions & Distribution Inc. are to be followed completely.  Use only recommended Adhesive available from Imperial for installation in addition to mechanical fasteners. All substrates must be properly constructed to verify substrate is plumb and true

Fire Rating

ASTM-C150 Standard Specification for Portland Cement 1999a

ASTM-E84 Standard Test Method for Surface Burning Characteristics of Building Materials 1990

 Material Specifications

 Physical Properties
High density concrete made of ASTMC 150 Portland cement, crushed stone, silica sand and polymers reinforced with continuous filament glass fiber mat and structural reinforced as required - asbestos free

Density: 140pcf (2240 kg/cu m)

Shell Thickness 3/8" to 3/4" (9.5mm) nominal

Surface Burning Characteristics: Flame spread index of 0, smoke developed index of 5

Weather resistance: No significant loss in strength or change in appearance after 200 hours accelerated weathering conducted in accordance with ASTMG-23

Flexural Strength 1000 to 1800 psi (5.9 to 12.4 MPa)

Modulus of Elasticity: 1.4 x 106 to 2.9 x 106

Compression Strength: Over 5000 psi (34 MPa)

Variations from Dimensions 1/16" to 1/8" (1.5 to 3mm)

 Manufacturing Process:

 The raw materials are mixed into a slurry and sprayed into molds.  After a mist coat is applied,

 a chopper gun introduces the fiber to the matrix to reinforce the ZeamentTM.

 The ZeamentTM part is allowed to dry in the mold.  It is then trimmed and demolded.

 Depending on the finish, the surface may be sandblasted, then protected with a factory applied

 concrete sealer.

 Building Codes

 As there are numerous dominant Building Codes in existence and practice throughout

 North America, in addition to the many State-level and Provincial codes, Imperial strongly urges

  Specifiers and users to refer to their local codes as to the uses any building components

 before buying product.
